seconds. It also has a second line where it directs any packets that cannot be transmitted in the first line in a T-second period. Find the average number of packets that are transmitted on the first line and the average number of packets that are transmitted in the second line.
Q3. (2 marks)
Five stations (S1-S5) are connected to an extended LAN through transparent bridges (B1-B2), as shown in the following figure. Initially, the forwarding tables are empty. Suppose the following stations transmit frames: S1 transmits to S5, S3 transmit to S2, S4 transmits to S3, S2 transmits to S1, and S5 transmits to S4. Fill in the forwarding tables with appropriate entries after the frames have been completely transmitted.
S1
S2
S3
S4
S5
LAN1
LAN2
LAN3
B1
B2
Port 1
Port 2
Port 1
Port 2
