A 1.5 Mbps communications link is to use HDLC to transmit information to the moon.What is the smallest possible frame size that allows continuous transmission? The distance between earth and the moon is approximately 375,000 km, and the speed of light is 3 x 108 meters/second.
Q2. (2 marks)
FOOVERFLOW.COM
Suppose that a multiplexer receives constant-length packet from N = 60 data sources.Each data source has a probability p = 0.1 of having a packet in a given T-second period.Suppose that the multiplexer has one line in which it can transmit eight packets every T seconds. It also has a second line where it directs any packets that cannot be transmitted in the first line in a T-second period. Find the average number of packets that are transmitted on the first line and the average number of packets that are transmitted in the second line.
Q3. (2 marks)
Five stations (S1-S5) are connected to an extended LAN through transparent bridges (B1-ERFLOW.COMB2), as shown in the following figure. Initially, the forwarding tables are empty. Suppose the following stations transmit frames: S1 transmits to S5, S3 transmit to S2, S4 transmits to S3, S2 transmits to S1, and S5 transmits to S4. Fill in the forwarding tables with appropriate entries after the frames have been completely transmitted.
